High performance best price SEM832F bulldozer best price on sale
SEM832F bulldozer features,
Proven Performance
Boost productivity with fully hydrostatic transmission
Effortless counter rotations, power turn, and infinitely variable speed control
Versatile operating modes for more efficient operations
World-class engine delivers superior durability and excellent fuel efficiency
Exceptional Reliability
World-class original pumps and motors
Standard configuration tubular track roller frame and Sealed and Lubricated Track (SALT)
Reinforced structures, analyzed using Finite Element Analysis (FEA)
Final drive with triple-stage reduction and dual-motor input
Modular cooling system designed to endure -40°C to +50°C ambient temperatures
Comfortable Operation
Spacious cab with easy-to-operate controls
Stylish design from the new F series
Six-way adjustable seat for quick customization according to the operator’s preferences
Exceptional visibility for enhanced on-site awareness
SEM832F bulldozer specification,
| Model | 832F | |||
| Main Specifications | ||||
|---|---|---|---|---|
| STD | DS | CH | WH | |
| Operating Weight (w. SU blade, Ripper) | 38,710kg | 39,390kg | 39,455kg | 40,110kg |
| Ground Pressure (GB/T 30965) | 83Kpa/77Kpa | 63Kpa | 78Kpa | 64Kpa |
| Minimum Ground Clearance (Excludes Grouser Height) | 370mm | |||
| Gradeability | 30° | |||
| Engine | ||||
| Engine Model | 1706D-E93TA | |||
| Advertised Power (ISO 14396) | 253kW/339hp | |||
| Rated Speed | 2,200r/min | |||
| Powertrain | ||||
| Transmission Type | Dual-path, closed loop electronically controlled hydrostatic drive system | |||
| Travel Speeds – Forward and Reverse | Infinitely variable speeds 0-11 km/h | |||
| Steering and Brake | Hydrostatic steering, wet,multi-disc brake, bellville spring actuated and hydraulically released | |||
| Implement Hydraulic | ||||
| Type | Double pump confluence, pilot control | |||
| System Pressure | 20MPa | |||
| Pump Type | Gear pump | |||
| Blades | ||||
| Blade Type | SU | S | Coal | S -WH |
| Blade Capacity (ISO 9246) | 9.6m³ | 7.8m³ | 12.9m³ | 18.6m³ |
| Blade Width (w/End Bit) | 4,180mm | 4,290mm | 4,760mm | 4,335mm |
| Blade Height | 1,710mm | 1,590mm | 1,710mm | 2,350mm |
| Blade Lifting Height | 1,206mm | |||
| Blade Digging Depth | 558mm | |||
| Blade Tilt Height (Middle Hole) | 905mm | 930mm | 1,030mm | 945mm |
| Blade Weight (w/o Push Arm) | 3,020kg | 2,840kg | 3,550kg | 3,300kg |
| Minimum Turning Radius | 4,590mm | 4,475mm | 4,990mm | 4,485mm |
| Single Shank Rippers | ||||
| Type | Parallelogram (No pitch adjustment) | |||
| Maximum Penetration (Shank Pinned in the Top Hole) | 1,216mm | |||
| Maximum Clearance Under Tip (Shank Pinned in the Bottom Hole) | 812mm | |||
| Ripper Weight | 4,160kg | |||
| Undercarriage | ||||
| Track Shoe Width | 560mm/610mm | 760mm | 610mm | 760mm |
| Track Shoes Number (Each Side) | 41 | |||
| Track Rollers Number (Each Side) | 7 | |||
| Carrier Roller Number (Each Side) | 2 | |||
| Dimensions | ||||
| Track Guage | 2,180mm | |||
| Width of Tractor, Trunnions Outside | 3,280mm | |||
| Machine Height, w/o Grouser | 3,440mm | |||
| Rops, w/o Grouser | 3,445mm | |||
| Alarm, w/o Grouser | 3,590mm | |||
| Exhaust Stack, w/o Grouser | 3,385mm | |||
| Length of Track on Ground | 3,200mm | |||
| Length of Basic Tractor, w. Drawbar | 5,645mm | |||
| SU Blade | 1,175mm | 1,175mm | 1,175mm | N/A |
| S Blade | 965mm | 965mm | N/A | N/A |
| U Blade | 1,575mm | N/A | 1,575mm | N/A |
| WH Blade | N/A | N/A | N/A | 965mm |
| Single-Shank Ripper | 2,020mm | 2,020mm | 2,020mm | N/A |
| Grouser Bar Height | 80mm | |||
| Drawbar Height (Pin Center) | 800mm | |||
